DeviceNet/PROFIBUS DP Gateway
- Fast and reliable linking PROFIBUS DP and DeviceNet with data buffering, at the DeviceNet and PROFIBUS DP networks the gateway operates as slave.
|
| |
| |
| |
DeviceNet Chip DN1022
- First DeviceNet slave ASIC.
- DN1022 makes a cost optimized design of intelligent DeviceNet Slave applications possible.
- It handles the physical layer 1; the data link layer 2 and application layer of the ISO/OSI-reference-model excluding the analog CAN receive transmit drivers .
|
 |
| |
| |
| |
 |
Modbus/PROFIBUS DP Gateway
- The gateway can connect multiple devices with Modbus/RS485/RS232/RS422 interface with PROFIBUS DP, and establish the communication between them. Modbus/RS485/RS232/RS422 network devices can be converted to PROFIBUS DP network devices.
|
| |
| |
| |
CANopen/PROFIBUS DP Gateway
- Fast and reliable linking PROFIBUS DP and CANopen with data buffering, the gateway acts as master or slave at the CANopen network and as slave at the PROFIBUS DP network.
|
 |
| |
| |
| |
| |
 |
Modbus/DeviceNet Gateway
- Fast and reliable linking Modbus/other protocol (User can define the protocol) to DeviceNet with data buffering, the gateway operates as slave at the DeviceNet network; Serial interface Supports RS485/RS422/RS232.
|
| |
